產品特征Features
◆本開關結構緊湊效率高，大面積的固定式散熱片為開關的安裝提供方便。開關內部為單極常開帶直通接點結構，通過改變輸入脈沖的占空比來控制場效應管的輸出電壓，而實現電子調速功能。
◆開關輸出端的平均電壓為總電壓的8- 50%至8- 90%，也可以按客戶要求進行定制，開關按到底由直通接點接至電池端電壓。
◆可選帶以下功能或附件：
→外置MOS管
→外接發光LED及導線
◆The switches combine compact size with high performance, a wide scope of heat sink for MOSFET and further options provide easy to mount solutions. They employ SPST-NO with by-pass contact, integrated PWM (Pulse Width Modulated) electronics in various dimensions.
◆Average duty cycle of motor voltage 8 - 50% to 8 - 90%, then by-pass to battery voltage (according to customer's demand).
◆Optional with the function or accessory as follows:
→Extrenal MOSFET version
→Auxiliary LED and wires
技術數據Technical data
→機械耐久壽命 Mechanical life endurance≥5E4
→電氣耐久壽命 Electrical life endurance≥1E4
→最大電流 Max. current at 36Vd.c25A
→接觸電阻 Contact resistance≤30m Ohm
→絕緣電阻 Insulation resistance≥7M Ohm
→基本介電強度 Dielectric strength of function500V
→加強介電強度 Dielectric streng th of reinforced500V
→環境溫度 Ambient temperature0°C~55°C
→阻燃等級 FlammabilityUL 94V-0
→防護等級 Protection typeIP40
◆開關內部電子部分在相應使用中一并做過相關測試,本開關適合做二類器具開關使用.
◆The electronics in the switches had to be tested together with the corresponding appliances, So the switches are suitable for appliance of class II .
端子類型Terminals
◆輸入端/輸出端 Input side/Output side:
→焊接端子 Solder terminal 48X0.8mm
