◆FDC系列是一款專用型的倒扳開關，也叫搖桿開關或撥動開關，應用于各類電動工具，如：電木銑、臺式砂輪機等。
◆FDC series are one special type Lever switch, for used in power-tools such as Routers, Bench Grinders, etc.
產(chǎn)品特征Features
◆可選帶以下功能 Optional with following function:
→單極單擲 SPST (Single Pole Single Throw)
→單極雙擲 SPDT (Single Pole Double Throw)
技術數(shù)據(jù)Technical data
→機械耐久壽命 Mechanical life endurance≥1E5
→電氣耐久壽命 Electrical life endurance≥5E4
→最大沖擊電流 Max.Inrush current at 250V60A
→最大沖擊電流 Max.Inrush current at 127V96A
→接觸電阻 Contact resistance≤30m Ohm
→絕緣電阻 Insulation resistance≥7M Ohm
→基本介電強度 Dielectric strength of function1500V
→加強介電強度 Dielectric strength of reinforced3000V
→環(huán)境溫度 Ambient temperature0°C~55°C
→阻燃等級 FlammabilityUL 94V-0
→防護等級 Protection typeIP40
→適用于II類防護器具 Suitable for appliances of protection class II
